Characteristics |
|
| |
CARE 40 is pure propane (R290) |
 |
| |
|
 Primarily for use in commercial air-conditioning and commercial
and industrial refrigeration systems that have traditionally used R502. |
| Operates at slightly lower pressures than R502 and R404A. |
| Possesses similar volumetric refrigerating effect to R12 and R134a. |
| Possesses similar volumetric refrigerating effect to R502 and R404A. |
| Compatible with most common refrigeration materials and lubricants. |
| Compatible with most common refrigeration materials and mineral oils. |
| Replacement : R-22, R-404a, HFC-407C, HFC-507 |
Application Range : Domestic air-conditioners, commercial fridges
in supermarkets. All kinds of chillers in hotels, factories, department
stores, buildings. |
Packing : 500gr/CAN, 3Kg/10 Kg/20 Kg/50 Kg Cylinder, Bulk Tank,
ISO Tank Container |
Packing : 500gr/CAN, 3Kg/10 Kg/20 Kg/50 Kg Cylinder, Bulk Tank,
ISO Tank Container |
| |
|
|
Physical Properties |
|
| |
| Product |
EP290 |
R502 |
R404A |
| Chemical Type |
HC |
111.6 |
HFC |
| Molecular Mass ( Kg/Kmol ) |
44.1 |
111.6 |
100.6 |
| Density ( Kg/m3 ) ★ |
494.3 |
1192.0 |
1042 |
| Temperature Range |
high, medium, low |
- |
- |
| Ozone depletion potential (CFC-11=1) |
0 |
0.28 |
0 |
| Global warming potential (CO2=1, 100yr ITH) ◇ |
3 |
6200 |
4540 |
| Normal boiling point (1.0 bar, abs) ★ |
-42.1℃ |
-45.4℃ |
-46.6℃ |
| Latent heat (1.0 bar, abs) ★ |
439 kJ/Kg |
174 kJ/Kg |
139 kJ/Kg |
| Toxicity |
None |
None |
None |
| Refrigerant mass charge size (R12=100%) |
41% |
100% |
86% |
| Lubricant |
Mineral |
Mineral |
Ester | |
| |
|
|
| |
* All conditions given at +25℃ (dew point).
★ Boiling points at standard atmospheric pressure (101.325kPa)
◇ CO2 GWP based on 100 year integration time horizon, defined in the Intergovernmental Panel for Climate Change (IPCC)
* Scientific Assessment 1994, CO2 = 1. |
| |
|
|
|
|
